New site - PIX4Dcloud
A site in PIX4Dcloud Pro is a collection of datasets from a specific location or project area. Sites enable timeline-based visualization, comparison of datasets over time, and access to Pro-exclusive features such as advanced monitoring and design overlay tools. This article explains why and when to create a site and provides step-by-step instructions for creating new sites in PIX4Dcloud Pro.
Licenses: This article is only valid for PIX4Dcloud Pro licenses (formerly PIX4Dcloud Advanced).
Roles: Only Owners, Managers, and Editors can create or manage sites in PIX4Dcloud Pro.
Video: The following video tutorial explains step-by-step how to organize Sites within PIX4Dcloud Advanced.
Why create a site
A site groups multiple datasets in a single location and allows them to take advantage of features exclusive to PIX4Dcloud Pro, including:
-
Timeline-based dataset navigation
-
Design overlay and comparison tools
-
2D/3D time-based visualization
When to create a new site
A dataset must be assigned to a site to access the full functionality of PIX4Dcloud Pro. New sites can be created in the following situations:
- Before creating a dataset.
- While creating a new dataset, whose site has not been created in advance.
- After uploading the project files from PIX4Dmapper.
How to create a new site
Before creating a dataset
- At the top left of the Drive, click New and select New site.
- Enter the name of the new site.
- Click Create site.
The new site will appear in the Drive.
While creating a new dataset
-
In the New dataset wizard, during Step 1 – Dataset creation, locate the field Assign my dataset to.
-
Type the name of the new site.
-
Click CREATE NEW SITE in the drop-down menu.
After the dataset is created, the new site will appear in the Drive.
After uploading the project files from PIX4Dmapper
-
Assign the uploaded dataset to a site.
-
If the site does not exist, create a new site during this assignment process.
Information:
-
If the Create New Site option is unavailable or grayed out, the account does not have a valid PIX4Dcloud Pro license.
-
Users who previously had a Pro license and now have a Starter license retain access to previously created sites but cannot create new sites.
